Optical fiber distribution box
SUP-HGJC6007  is used as a termination point for the feeder cable to connect with drop cable in FTTx
communication network system. The fiber splicing, splitting, distribution can be done in this box, and
meanwhile it provides solid protection and management for the FTTx network building.

Features
 User familiar industry interface, using high impact plastic ABS
 Up to 16 FTTH drops ,2 inlet ports, 16 outlet ports
 Wall and pole mountable
 No need screws , it is easy to close and open
 The high strength plastic, anti ultraviolet radiation and ultraviolet
radiation resistant, resistant to rain

Application
 Widely used in FTTH access network.
 Telecommunication Networks
 CATV Networks Data communications Networks
 Local Area Networks
